93C56-E/SN EEPROM L56R

Name: 93C56-E/SN EEPROM L56R
Brand: Mouser
SKU: 93C56-E/SN
Price: 211.14 NOK
Availability: InStock

kr211,14 In Stock Sold out

SKU: 93C56-E/SN

Categories: EEPROM

1-4 DAGER LEVERING

100 % KVALITET

12 MÅNEDERS GARANTI

93C56-A/B/C EEPROM L56R

Images are for reference only
See Product Specifications

93C56-E/SN

Microchip Technology

Description:

EEPROM 256x8-128x16

Datasheet:

Mfr.:

Microchip Technology

Mfr. No:

93C56C-E/SN

Description:

EEPROM 128x8 Or 64x16

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Microchip
Product Category:	EEPROM
RoHS:
Memory Size:	2 kbit
Interface Type:	3-Wire, Microwire
Maximum Clock Frequency:	2 MHz
Organisation:	256 x 8/128 x 16
Package/Case:	SOIC-8
Access Time:	400 ns
Supply Voltage - Min:	4.5 V
Supply Voltage - Max:	5.5 V
Mounting Style:	SMD/SMT
Data Retention:	40 Year
Minimum Operating Temperature:	- 40 C
Maximum Operating Temperature:	+ 125 C
Series:	93C56A/B/C
Packaging:	Tube
Active Read Current - Max:	4 mA
Brand:	Microchip Technology
Height:	1.25 mm (Min)
Length:	4.9 mm
Moisture Sensitive:	Yes
Operating Supply Current:	500 uA, 100 uA
Operating Supply Voltage:	4.5 V to 5.5 V
Product Type:	EEPROM
Programming Voltage:	4.5 V to 5.5 V
	100
Subcategory:	Memory & Data Storage
Supply Current - Max:	4 mA
Width:	3.9 mm
Unit Weight:	540 mg
